Designed by Francesco Paszkowski and fitted with the most modern equipment, she has been built with a large boarding ladder to allow the full access of a wheelchair to all decks.
With zero speed quantum stabilizers, che is a true world cruising yacht with a range of 5000nm and 4 generators. She is MCA compliant and run under ISM and ISPS code for safety and security.

MASTER STATEROOM
The full beam master bedroom with large picture windows on either side is reached from a special lobby area on the Main Deck. The dark floor covering created the foundation for the eye to travel around this large space, while the white walls and deck head create the airy headroom. Adjacent is the Master office, Master Lounge area and Master bathroom. The striking feature of the bathroom is the free standing oval bath and the tiled wall covering that brings colour and texture to the luxurious surroundings.

GUESTS’ STATEROOMS
The four “Queen” quest bedrooms have a similar layout and the signature white design for each. Individuality is created by different colour-ways in each cabin.
The total accommodation of 12 guests aboard ‘BARAKA’ comprises of the master suite, four ‘Queen’ guest suites and a VIP suite on the Main Deck.

The 13 Crew enjoy no less than six crew cabins supported by a large mess area, plus 1 cabin for the master, located in the upper deck close to the bridge.

MECHANICAL EQUIPMENT

ENGINES 2 x 1,911 Hp CAT
ENGINE HOURS As of January 2017
Port: 3,800 hours; Stbrd: 3,800 hours
GEARBOX Twin Disc MG 5600
PROPULSION Prop Shaft
STEERING Data
STABILISERS Quantum quite pack; zero speed
BOWTHRUSTER 175 kW Jastram
GENERATORS 2 x 150kW Caterpillar C9
HARBOUR GENERATOR 1 x 86kW Caterpillar C4
EMERGENCY GENERATOR 1 x 86kW Caterpillar C4
GENERATOR HOURS As of January 2017
Port: 9600hours; Starboard: 9400hours
HARBOUR GEN. HOURS 250h (January 2017)
EMERGENCY GEN. HOURS 27 hours (January 2017)
ELECTRICITY 380V /3 phase /50Hz
2015)
ELECTRICITY 380v /3 phases /50 Hz
BATTERIES All gel type
AIR CONDITIONING 4 x 50’000 BTU AC units variable
capacity compressors for ER
2 x 400’000 BTU AC units variable
capacity compressors for
accommodation
WATER MAKER 2 x Idromar - 12,000 litres per day each
FRESH WATER SYSTEM Gianneschi & Ramacciotti
SEWAGE SYSTEM Hamann Wasser Technic
FUEL SEPARATOR Alfa Laval fuel separators w/ Racor filter
BILGE WATER SEPARATOR Solas approved RWO

NAVIGATION EQUIPMENT

MAGNETIC COMPASS Cassens & Plath
GYRO COMPASS Anschütz Std 22G
AUTOMATIC PILOT Sperry Marine
RADAR 1 x S Band Furuno FAR 2137
1 x X Band Furuno FAR 2117
DGPS GPS GP-150 Furuno Imo approved
DGPS GP-37 Furuno Imo approved
CHARTS Furuno ECDIS FEA 2107 chart plotter
NAVTEX Furuno NX 700A
LOG Furuno Dopller speed log
WIND INSTRUMENTS Furuno WS 200 wind station
SEARCHLIGHTS/SONAR Furuno IMO type + Furuno searchlight
sonar

COMMUNICATION EQUIPMENT

SATCOM Orbit V-SAT for Voip communication
VHF Sailor RT 5200
SSB Furuno FS-1570 SSB
LANDLINE/INTERCOM Furuno Intercom
Panasonic PABX TDX 100
Telular GSM phone and fax
WI-FI 4G Internet connection throughout

DECK EQUIPMENT

ANCHOR WINDLASS DATA
ANCHORS 2 x 540kg
ANCHO CHAINS 2 x 247.5m (812’)
AFT WARPING CAPSTAN DATA
CRANE & DAVITS Nautical Structure EZ 2500 sun deck
crane
Sanguineti Chiavari Solas crane
Nautical structure Garage crane SL
2200-SL2500 for 2 tenders
PASSERELLE Sanguineti Chiavari wide passerelle for
the passage of a wheelchair
JACUZZI Riviera Pool on sun deck

ENTERTAINMENT EQUIPMENT
• Sky box TV Sea Tel in master cabin, sky lounge, gym , crew mess
and captain cabin
• HiFi system in every area with Air Play & Bluetooth
• Crestron Entertainment System Software
• Mini Ipad remote controls
• Apple TV on streaming

GALLEY & LAUNDRY EQUIPMENT

GALLEY
All equipment in galley is Electrolux and Miele
• Induction plate
• Deep fryer
• Oven
• Steam oven
• Microwave oven
• Grill salamander
• Trash compactor
• Fast dish washer
• Blast Chiller

LAUNDRY
All equipment in Laundry is Miele industrial type
• 3 x Washing machines
• 3 x Dryers
• Lift from Laundry to Upper deck
SECURITY & SAFETY EQUIPMENT
SAFETY
• CCTV system
• Bridge plus Crew Mess TV’s monitors
• 6 x Cameras (6 remote – 3 orientable and 3 fix)

FIRE FIGHTING
• Hi Fog sprinkler system
• Smoke hood in every cabin
• Full set of immersion suite

TENDERS & WATERSPORTS EQUIPMENT

TENDERS
• 1 x 9.50m Lomac Adrenalina with 2x250hp engines
• 1 x 4.50m Jeb 40Hp outboard Tohatsu engine

WATER SPORTS
• 2 x rigid kayaks
• 2 x Inflatable kayaks (single or double)
• A selection of snorkelling gear and flippers
• 2 sets for diving adult (RDV Diving)
• Wake board
• Kneeboard
• Skurfboard
• Donut
• Banana
• 2 x Inflatable Paddleboards
• NO JETSKIS
