Cantiere delle Marche 30.8 m. Cantiere delle Marche30.8 m.
Main Characteristics
| Length O.A.: | 101 ft. / 30.79 m. |
| Beam: | 7.43 m. |
| Engines: | 2x CAT C18 680HP |
| Cruising Speed: | 11 knots |
| Top Speed: | 13 knots |
| Fuel Capacity: | 40000 lts |
| Water Capacity: | 6000 lts |
More infoBuilder
Built by Cantiere delle Marche in 2019
Accommodation
Cabins: 5 | Guests: 10
Asking Price
€ 11,000,000
Sales Enquiry
Description
Accommodation
Accommodation for up to 10 guests in 5 cabins and up to 6 crew.
GUEST CABINS 1 x Master cabin
2 x Double cabins
2 x Twin cabins
CREW CABINS 1 x Captain cabin
2 x Crew cabins
GUEST CABINS 1 x Master cabin
2 x Double cabins
2 x Twin cabins
CREW CABINS 1 x Captain cabin
2 x Crew cabins
Equipment
SPEED & RANGE UNDER POWER
MAXIMUM SPEED 13 knots
CRUISING SPEED 11 knots
FUEL CONSUMPTION Approx. 60 litres per hour @ 10 knots
RANGE 4,500 nm @ 10 knots
CAPACITIES
FUEL 40,000 litres / 10,600 US gallons
FRESH WATER 6,000 litres / 1,585 US gallons
GREY WATER 2,100 litres / 550 US gallons
BLACK WATER 1,100 litres / 290 US gallons
BILGE 1,100 litres / 290 US gallons
DIRTY LUBE OIL 300 litres / 80 US gallons
NAVIGATION EQUIPMENT
• 4 x Hatteland display 19”
• Furuno main radar
• ARPA FAR-2117BB-12KW-IMO version
• Furuno navnet 3d blackbox- second radar
• Chart plotter
• Map media chartforn avnet 3d system
• Navigation pc & maxsea navigation sw
• Furuno GPS#1 GP-33
• Furuno professional nmea splitter
• Furuno autopilot nav-700
• Furuno AIS classa transponder FA-170
• Furuno network sounder DFF1
• blackbox & transducer
• Fruno professional hub for navne
• TTZT network
• Furuno FI -70 data repeters –
• Wind sensor &log /temp/depth sensor
• Furuno satellite comp SSSC-50/ GPS #2
• Furuno fluxgate- backup heading
• Furuno main VHF DSC class A GMDSS
• Ocean signal EPIRB (GMDSS)
• Ocean signal SART (GMDSS)
• Ocean signal VHF port (GMDSS)
• Ritchie magnetic compass
• Furuno VHF SSC DSC class D
• Furuno VHF secondary station
• FRMOFM -4721 for crew mess
• 3 x Cameras (garage, engine room, main deck cockpit) & touch panel controldisplay
• Fly bridge station:
• Furuno multifunction display
• Furuno autopilot display
MECHANICAL EQUIPMENT
ENGINES
2 x CAT C18 Acert 500kW – 680hp
Engine hours: Stbd 2864 hrs, Port 2862 hrs (June 2024)
STABILISERS
CMC electrical (zero speed and underway)
BOWTHRUSTER
Electric 52 kW
GENERATORS
2 x 55 kW Kohler, Automatic parallel possible
Gen Hours: Stbd 6278.4 hrs, Port 6081.9 hrs (June 2024)
AIR CONDITIONING
Tropical Specification
WATER MAKER
Idromar 7,200 litres p/day
SEWAGE SYSTEM
Selmar Black water treatment
COMMUNICATION EQUIPMENT
ANTENNAS Tracvision TV-8 KVH
Gateway GSM 5 band for external calls and three
GSM antennas
FM receiver
DECK EQUIPMENT
ANCHOR WINDLASSES Muir VRC 6000
AFT WARPING CAPSTANS Muir VC 4000
Muir VRC 6000
ANCHORS 2 x 230 Kg
ANCHOR CHAINS 2 x 110 m, 16 mm
BOAT CRANE & DAVITS Sanguinetti (2,000 kg max load)
PASSERELLE Electro-hydraulic Bitecnomare “Magnum due” (5.30m x 0.60 m)
MAXIMUM SPEED 13 knots
CRUISING SPEED 11 knots
FUEL CONSUMPTION Approx. 60 litres per hour @ 10 knots
RANGE 4,500 nm @ 10 knots
CAPACITIES
FUEL 40,000 litres / 10,600 US gallons
FRESH WATER 6,000 litres / 1,585 US gallons
GREY WATER 2,100 litres / 550 US gallons
BLACK WATER 1,100 litres / 290 US gallons
BILGE 1,100 litres / 290 US gallons
DIRTY LUBE OIL 300 litres / 80 US gallons
NAVIGATION EQUIPMENT
• 4 x Hatteland display 19”
• Furuno main radar
• ARPA FAR-2117BB-12KW-IMO version
• Furuno navnet 3d blackbox- second radar
• Chart plotter
• Map media chartforn avnet 3d system
• Navigation pc & maxsea navigation sw
• Furuno GPS#1 GP-33
• Furuno professional nmea splitter
• Furuno autopilot nav-700
• Furuno AIS classa transponder FA-170
• Furuno network sounder DFF1
• blackbox & transducer
• Fruno professional hub for navne
• TTZT network
• Furuno FI -70 data repeters –
• Wind sensor &log /temp/depth sensor
• Furuno satellite comp SSSC-50/ GPS #2
• Furuno fluxgate- backup heading
• Furuno main VHF DSC class A GMDSS
• Ocean signal EPIRB (GMDSS)
• Ocean signal SART (GMDSS)
• Ocean signal VHF port (GMDSS)
• Ritchie magnetic compass
• Furuno VHF SSC DSC class D
• Furuno VHF secondary station
• FRMOFM -4721 for crew mess
• 3 x Cameras (garage, engine room, main deck cockpit) & touch panel controldisplay
• Fly bridge station:
• Furuno multifunction display
• Furuno autopilot display
MECHANICAL EQUIPMENT
ENGINES
2 x CAT C18 Acert 500kW – 680hp
Engine hours: Stbd 2864 hrs, Port 2862 hrs (June 2024)
STABILISERS
CMC electrical (zero speed and underway)
BOWTHRUSTER
Electric 52 kW
GENERATORS
2 x 55 kW Kohler, Automatic parallel possible
Gen Hours: Stbd 6278.4 hrs, Port 6081.9 hrs (June 2024)
AIR CONDITIONING
Tropical Specification
WATER MAKER
Idromar 7,200 litres p/day
SEWAGE SYSTEM
Selmar Black water treatment
COMMUNICATION EQUIPMENT
ANTENNAS Tracvision TV-8 KVH
Gateway GSM 5 band for external calls and three
GSM antennas
FM receiver
DECK EQUIPMENT
ANCHOR WINDLASSES Muir VRC 6000
AFT WARPING CAPSTANS Muir VC 4000
Muir VRC 6000
ANCHORS 2 x 230 Kg
ANCHOR CHAINS 2 x 110 m, 16 mm
BOAT CRANE & DAVITS Sanguinetti (2,000 kg max load)
PASSERELLE Electro-hydraulic Bitecnomare “Magnum due” (5.30m x 0.60 m)
View more
View less
BUILDER Cantiere delle Marche
NAVAL ARCHITECT Hydro Tec S.r.l.
EXTERIOR DESIGN Hydro Tec S.r.l.
INTERIOR DESIGN Francesco Guida
CLASSIFICATION RINA, registered pleasure. Built in compliance with commercial LY3 code
CONSTRUCTION Steel Hull, Aluminium Superstructure, Teak Decks
ENGINES 2 x CAT C18 Acert 500kW – 680hp
GT 246
DISPLACEMENT 240 tons
DIMENSIONS
LOA 31.00m / 102’8’’
BEAM 7.34m / 24’4’’
DRAFT 2.45m / 8’1’’
